Description

The pneumatic control valve is composed of an actuator and an adjustment mechanism. The actuator is the thrust component of the adjustment valve. It generates a corresponding thrust according to the pressure of the control signal to push the adjustment mechanism into action. The valve body is the regulating component of the pneumatic regulating valve. It directly contacts the regulating medium to regulate the flow, pressure, temperature and other process parameters of the fluid. The pneumatic control valve has the characteristics of simple control, fast response, and intrinsically safe, without additional explosion-proof measures. Pneumatic control valve is one of the industrial process control instruments widely used in petroleum, chemical, electric power, metallurgy and other industrial enterprises.

Model: pneumatic control valve
Size Range: 3/4''~8'
Pressure Range: PN16~PN100
Material: WCB, HT200、ZG25I、ZG1Cr18Ni9、ZGOCr17Ni12Mo2、1.25Cr0.5Mo、5.0Cr0.5Mo、 SCPH21、Ti

Lining: PTFE
